QB 3 FAR RED
Sold Out
Specifications
- Forward Voltage Vf = 6.7 VDC -7.0 VDC @ 1000mA
- 220 mm x 30mm
- Peak Wavelength 730nm
- Max Recommended Current 1000mA
- Recommended Installation: Screw, Double side adhesive tape.
Recommended Far Red LED Modules for even coverage
| Space in ft x ft | QB 3 Modules |
| 2x2, 2x2.5, 3x3 | 1 or more in Parallel |
| 4x4, 4x5, 5x5 | 2 in series |
| 6x6 | 3 in series |
Recommended Usage
Flowering Initiator. Power on for 3 to 10 minutes during transition from Lights On (Photo Period) to Lights Off (Dark Period).
Under normal conditions it can take up to 2 hrs to change Phytochrome state from Pfr to Pr. Flower Initiator helps change Phytochrome state from Pfr to Pr within minutes. This helps finish the flowering cycle faster and also allows for a 13/11 cycle.
Driver Options (Constant Current LED Driver only)
APC-8-700 - One or more QB 3 in Parallel
APC-12-700 - One or Two QB 3 in Series
APC-16-700 - Two or Three QB 3 in Series
APC-25-700 - Three or Four QB 3 in Series
LPC-20-700 - Three or Four QB 3 in Series
Meanwell LDD H are a great way of using standard 12v - 54V power supplies to power QB 3 strips. Standard 12V power supply can power 1 board with LDD. Standard 18V power supply can power 2 board in series on a LDD. Standard 24V power supply can power 3 board in series on a LDD. These step down DC-DC drivers are available in 300mA, 350mA, 500mA, 600mA, 700mA, 1000mA. LDD can convert 10 to 54VDC input into Constant Current to power for QB 3
LDD-300HW
LDD-350HW
LDD-500HW
LDD-600HW
LDD-700HW
LDD-1000HW
View full product details
Slate 5 Quad Extrusion
$129.00
Predrilled Heatsink for 4 x Quantum Boards
Details
- Pre Drilled for upto 4x QB304 or 4x QB288 Quantum Board
- Black Anodized
- Length:740 mm Width: 390 mm Weight: 11.25 lbs
- Predrilled for Meanwell HLG 600H and Inventronics EUD-600 power supply. Driver not included
- M3 Screws to mount boards included
Performance
- Thermal resistance 0.xx C/W ,W = Board driven Watts (Not thermal watts). Tested at Horizontal orientation with board facing down
- Recommended for upto 600Watts with 4 QB boards.
View full product details
Refurbished HLG 650R
Sold Out $799.00
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
HLG 650R Commercial Indoor Horticulture LED grow light is designed to replace a double-ended 1000 watt HID lamp. 650 R uses 4 of our custom designed full spectrum high efficiency white light quantum boards with Samsung LM301H and Deep Red LED 660nm . This unit is dimmable, with wattage output from 60 to 610 watts.
View Report for Output & Efficiency
Top Features
- 2.81 PPF/W High Efficiency at 630 watts
- 1770 PPF High Output to replace even 1000W DE
- Quantum Board® QB 648 made by Samsung
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- 60 to 630 Watts Dimmable design
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 1 Year Warranty on Refurbished lamps
PPFD Chart at 24 inches and 30 inches
Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
Specifications
| Power | 60-630 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 5' x 5' at 30" |
| Veg Footprint | 7' x 7' at 48” |
| System PPF Efficacy | 2.81 μmol/joule |
| Total output | 1770 PPF |
| Dimensions | 26" x 21.25" x 4" |
| Recommended Mounting Height | 30-36 inches above canopy |
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
View full product details
Refurbished Scorpion Diablo
Optimized for Vertical Rack Grows
$999.00
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
HLG Scorpion Diablo is designed for grows with low ceiling heights or for vertical racks. HLG Scorpion Diablo uses 6x QB648 Diablo Quantum Boards® for an even light spread at just 12" from the canopy. This is a very efficient full spectrum horticulture lamp with an efficiency of 2.9 PPF/W
HLG Scorpion Diablo Manual
Independent Efficiency Lab Report
Independent PPFD Report
Top Features
- Designed for low ceiling heights or vertical racks
- Highest efficiency full spectrum grow lamp
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 1 Year warranty on Refurbished Lamps
Specifications
| Power | 60-650 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 5' x 5' at 18" |
| Veg Footprint | 6' x 6' at 24” |
| System PPF Efficacy | 2.9 μmol/joule |
| Total output | 1900 PPF |
| Dimensions | 38.5" x 36" x 2.75" |
| Recommended Mounting Height | 12-18 inches above canopy |
Watts to BTU Calculator, Cooling Requirement Calculator
*Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
View full product details
Refurbished Scorpion Rspec
Optimized for Vertical Rack Grows
Sold Out
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
HLG Scorpion R Spec is designed for grows with low ceiling heights or for vertical racks. HLG Scorpion R Spec uses 6x 288 Quantum Boards for an even light spread at just 12" from the canopy. QB288 uses Samsung's latest LM301H and Deep Red LED 660nm. This unit is dimmable, with wattage output from 60 to 600 watts.
HLG Scorpion R Spec Manual
Independent Efficiency Lab Report
Independent PPFD Report
Top Features
- Designed for low ceiling heights or vertical racks
- High efficiency white light Quantum Boards®
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 1 Year warranty on Refurbished Lamps
Specifications
| Power | 60-600 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 5' x 5' at 18" |
| Veg Footprint | 6' x 6' at 24” |
| System PPF Efficacy | 2.62μmol/joule |
| Total output | 1584 PPF |
| Dimensions | 38.5" x 36" x 2.75" |
| Recommended Mounting Height | 12-18 inches above canopy |
Watts to BTU Calculator, Cooling Requirement Calculator
*Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
View full product details
Refurbished HLG 550 V2 Rspec
Ideal for Flowering/Full Cycle
$599.00
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
HLG 550 V2 R Spec Commercial Indoor Horticulture LED grow light is designed to replace a single-ended 1000watt HID. Each HLG 550 V2 uses 4 of our custom designed full spectrum high efficiency white light quantum boards with Samsung LM301H and Deep Red LED 660nm . This unit is dimmable, with wattage output from 200 to 500 watts.
DOWNLOAD HLG 550 V2 R SPEC MANUAL
View Report for Output/Efficiency
Top Features
- High efficiency white light Quantum Boards®
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 1 Year warranty on Refurbished Lamps
- Higher intensity and more even coverage in a grow tent, reflective area, or by crossing over using multiple HLG-550 V2 lamps.
Specifications
| Power | 40-500 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 4.5' x 4.5' or 4' x 5' at 24" |
| Veg Footprint | 6' x 6' at 36” |
| System PPF Efficacy | 2.65 μmol/joule |
| Total output | 1293 PPF |
| Dimensions | 26" x 20" x 4" |
| Recommended Mounting Height | 24-32 inches above canopy |
Report for PPFD 24 inches 5' x 5'
Report for PPFD 18 inches 5' x 5'
Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
Refurbished HLG 600 Rspec®
Sold Out $849.00
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
Our HLG 600 Rspec® Commercial Indoor Horticulture LED grow light is designed to replace 1000watt HID. Each HLG 600 uses 4 of our custom designed full spectrum high efficiency white light quantum boards with Samsung LM301H and Deep Red 660nm LED's. This unit is dimmable, with wattage output from 60 to 600 watts.
DOWNLOAD HLG 600 R SPEC MANUAL
HLG 600 R Spec Independent Lab Report
Top Features
- High efficiency white light Quantum Boards®
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 3 Year warranty
Specifications
| Power | 60-600 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 5' x 5' at 28" |
| Veg Footprint | 6' x 6' at 40” |
| System PPF Efficacy | 2.55 μmol/joule |
| Total output | 1522 PPF |
| Dimensions | 26" x 21.5" x 2.75" |
| Recommended Mounting Height | 28-36 inches above canopy |
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
View full product details
Refurbished HLG 550 V2 Bspec
Sold Out
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
Our HLG 550 V2 B Spec Commercial Indoor Horticulture LED grow light is designed to replace a single-ended 1000watt HID. Each HLG 550 V2 uses 4 of our custom designed full-spectrum high efficiency white light quantum boards with Samsung LM301H and Blue 470nm . Learn more about the individual QB-288 boards here. This unit is dimmable, with wattage output from 200 to 480 watts.
DOWNLOAD HLG 550 V2 B SPEC MANUAL
HLG 550 V2 Independent Lab Test Report 1
Top Features
- High efficiency white light Quantum Boards®
- Full Spectrum White and 470nm Blue
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 1 Year warranty on Refurbished Lamps
- Higher intensity and more even coverage in a grow tent, reflective area, or by crossing over using multiple HLG 550 V2 lamps
Specifications
| Power | 240-480 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Blue |
| Veg Footprint | 6' x 6' at 36” |
| System Efficiency | 166 Lm/W |
| System PPF Efficacy | 2.55 μmol/joule |
| Total output | 1175 PPF |
| Dimensions | 26" x 20" x 4" |
| Recommended Mounting Height | 24-32 inches above canopy |
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
Refurbished HLG 550 V2 ECO
$499.00
Refurbished Lamps are tested and fully functional with HLG original components. May have Scratches and/or may have been previously used.
Our HLG 550 V2 ECO indoor Horticulture LED grow light is designed to replace a single-ended 1000watt HID, and offers the highest output and efficiency for your money. This unit is dimmable, with wattage output from 200 to 480 watts. 3000K Spectrum recommended for flowering and 4000K recommended for Veg.
Top Features
- High efficiency white light Quantum Boards®
- Full spectrum for better results
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing power supply works on both 120VAC and 240VAC
- 1 Year warranty on Refurbished Lamps
- Higher intensity and more even coverage in a grow tent, reflective area, or by crossing over using multiple HLG-550 V2 lamps.
Specifications
| Power | 40-480 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | 1296 pcs Samsung 301H |
| Flowering Footprint | 4' x 5' at 30" |
| Veg Footprint | 6' x 6' at 36” |
| System Efficiency | 171 Lm/W |
| System PPF Efficacy | 2.5 μmol/joule |
| Total output | 1200+ PPF |
| Dimensions | 26" x 20" x 3" |
| Recommended Mounting Height | 22-32 inches above canopy |
View full product details
QB132 V1 Quantum Boards
Sold Out
QB132 V1 Quantum Boards (4 Pack)
High efficiency boards designed for DIY projects. Each board can be powered up to 75 watts. No Thermal Interface Material or heatsink is required. Does not work with Slate series Heatsinks. Lumileds 2835HE LED
Specifications
- 4 piece QB 132 LED Boards
- 1 Molex Connectors, Push-Button Type
- Dimensions 300mm x 225mm
- 36V DC. Max current 2100mA
Board's power wires can optionally be soldered.
- Molex Connector
Wire can be pushed into the connector. To unmate, push down lever on the housing to allow the wire to be disengaged. Rated 300V 9A. Max 10 boards in series wiring.
Driver Options
- LPF-60-36 - 1x QB132
- HLG-185H-C1400 - 4x QB 132 in series
- HLG-240H-C1750 - 4x QB 132 in series
For more driver options check here
View full product details
HLG 550 V2 Rspec
Ideal for Flowering/Full Cycle
Sold Out
HLG 550 PHASE OUT MODEL
(3 Year warranty is still in effect)
Click here to order the latest upgrade model, the NEW HLG 600.
Our HLG 550 V2 R Spec Commercial Indoor Horticulture LED grow light is designed to replace a single-ended 1000watt HID. Each HLG 550 V2 uses 4 of our custom designed full spectrum high efficiency white light quantum boards with Samsung LM301H and Deep Red LED 660nm . This unit is dimmable, with wattage output from 200 to 500 watts.
DOWNLOAD HLG 550 V2 R SPEC MANUAL
HLG 550 V2 Independent Lab Reports
View Report for Output/Efficiency
Top Features
- High efficiency white light Quantum Boards®
- Full Spectrum White and 660nm Red
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 3 Year warranty
- Higher intensity and more even coverage in a grow tent, reflective area, or by crossing over using multiple HLG-550 V2 lamps.
Specifications
| Power | 40-500 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Deep Red |
| Flowering Footprint | 4.5' x 4.5' or 4' x 5' at 24" |
| Veg Footprint | 6' x 6' at 36” |
| System PPF Efficacy | 2.65 μmol/joule |
| Total output | 1293 PPF |
| Dimensions | 26" x 20" x 4" |
| Recommended Mounting Height | 24-32 inches above canopy |
Watts to BTU Calculator, Cooling Requirement Calculator
Report for PPFD 24 inches 5' x 5'
Report for PPFD 18 inches 5' x 5'
Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
Check HLG 550 V2 B Spec for Veg spectrum option
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
Expect higher intensity and more even coverage in a grow tent, reflective area or a cross over with multiple lamps.
View full product details
HLG 550 V2 Bspec
Sold Out
Our HLG 550 V2 B Spec Commercial Indoor Horticulture LED grow light is designed to replace a single-ended 1000watt HID. Each HLG 550 V2 uses 4 of our custom designed full-spectrum high efficiency white light quantum boards with Samsung LM301H and Blue 470nm . Learn more about the individual QB-288 boards here. This unit is dimmable, with wattage output from 200 to 480 watts.
DOWNLOAD HLG 550 V2 B SPEC MANUAL
HLG 550 V2 Independent Lab Test Report 1
Watts to BTU Calculator, Cooling Requirement Calculator
Check HLG 550 V2 R Spec for Flowering spectrum option.
Top Features
- High efficiency white light Quantum Boards®
- Full Spectrum White and 470nm Blue
- Reliable passive-cooled design
- Better canopy light penetration with diffused light
- Dimmable power supply included
- Auto sensing Inventronics power supply works on both 120VAC and 240VAC and 277VAC
- 3 Year warranty
- Higher intensity and more even coverage in a grow tent, reflective area, or by crossing over using multiple HLG 550 V2 lamps
Specifications
| Power | 240-480 Watts |
| Voltage Range | 100-277 VAC 50-60Hz |
| LED | Samsung LM301H & Blue |
| Veg Footprint | 6' x 6' at 36” |
| System Efficiency | 166 Lm/W |
| System PPF Efficacy | 2.55 μmol/joule |
| Total output | 1175 PPF |
| Dimensions | 26" x 20" x 4" |
| Recommended Mounting Height | 24-32 inches above canopy |
Conforms to UL Std 1598
Certified to CSA Std C22.2#250.0
Please contact for other spectrum options, 240V or UK, EU Power cords.
Datasheet of Samsung LM301H Datasheet used in R spec Quantum Board®
Expect higher intensity and more even coverage in a tent, reflective area or a cross over with multiple lamps.
View full product details
